Pressure
Pressure
Measurements
Calibrations of pressure gauges
  • From -1 … + 1000 bar
  • From -1 … +1 mbar and from -10 … +10 mbar
  • From 800 … 1200 mbar abs. and from 0.05 … 16 bar abs.
  • Using high accuracy reference standards (Dead Weigh Tester, DWT) and working standards (Standard electronic pressure gauges and pressure controllers) with accuracy ranging from 0.008 % … 0.025 %
  • Pursuant to the guidelines DIN EN 837, DAkkS-DKD-R 6-1, EURAMET cg-3 or EURAMET cg-17
Devices requiring calibration
  • All instruments measuring negative and positive pressure, differential pressure-including the differential pressure under static pressure and absolute pressure
  • Analogue pressure gauges
  • Electrical pressure transmitters and pressure sensors
  • Analogue differential pressure gauges
  • Pressure switches
  • Meters of fluid column / U-tube pressure gauges
  • Inclined pressure gauges
  • Pressure calibrators
  • Pressure controllers
  • Pressure recording instruments
  • Absolute and barometric pressure gauges
  • Differential pressure sensors
Mass
Measurements
in Mass
Calibration of laboratory and industrial scales
  • From 1 mg to 300 kg using standard weights
  • From 300 kg to 2000 kg using standard weights and additional weights
  • With an accuracy of 5.3 μg
  • According to the Euramet CG Directive 18
Devices that need calibration
  • Analytical weight machines
  • High precision weight machines
  • Moisture determination scales
  • Production scales
  • Pallet truck scales
  • Film scales
Temperature
Temperature
Measurements
Calibrations of temperature gauges and environmental chambers
  • Ranging from -80 … +1000 °C
  • Ranging from -80 … +250 °C (chambers)
  • In calibration baths, dry block calibrators and environmental chambers, using the most appropriate standard thermometers
  • With accuracy from 5 mK … 1.5 K
  • In accordance with the guidelines DKD/DAkkS and EURAMET
Devices requiring calibration
  • Temperature sensors with transmitters
  • Thermoresistances (Pt100, Pt1000 etc.))
  • Thermocouples (type ‘K’, ‘J’ etc.)
  • Temperature readers, hand-held gauges, temperature recording devices etc
  • Different types of sensors such as immersion sensors, surface sensors and air temperature measurement sensors
  • Test thermometers
  • Mechanical thermometers
  • Dry block calibrators
  • Temperature calibrators
  • Optical thermometers
  • Calibration baths
  • Incubation cabinets
  • Sterilization chambers
  • Environmental chambers
Humidity
Humidity
Measurements
Calibrations of humidity meters
  • From 15 … 95 % rH (at 25 or/and 40 οC)
  • In environmental chambers of changing conditions, fixed and portable
  • With accuracy ranging from 1 % rH
  • In accordance with guidelines DKD/DAkkS and EURAMET
Devices requiring calibration
  • Humidity sensors with transmitters
  • Humidity readers, hand-held gauges, humidity recording devices etc
  • Hair-tension humidity meters
  • Mechanical humidity meters
Quantities
Measurements of
Other Quantities
Meter calibrations of electrical quantities
  • Direct Current in the range of 0… 50 mA
  • DC voltage in the range of 0 … 20 V
  • DC resistance in the range of 0 … 10 kΩ
Calibrations of dimensional quantities
  • Vernier calipers-digital/Micrometers/Metal sheet thickness in the range of 0,5 … 1000 mm
  • Rulers/Measuring tapes in the range of
  • Paint thickness gauge in the range of 12,5 … 500 μm
Calibration of volumetric equipment
  • From 10 μL… 20 mL (Automatic piston pipettes – Pipettes of fixed or variable volume)
  • From 100 μL to 10 lt (Volumetric equipment and liquid dispensers)
  • Using state of the art weighing systems
  • Accuracy from 0.2 μL
  • According to the instructions DKD / DAkkS and EURAMET
Calibrations
Calibrations at
Your Premices
Calibrations of scales, pressure gauges, temperature gauges, humidity meters

To achieve the minimum possible impact on your manufacturing process and to save time, we offer you on-site calibrations – and by accredited methods in accordance with DIN EN ISO / IEC 17025 – anywhere in Greece, for measuring instrument of mass, pressure, temperature, and humidity.

  • In scales from 1 mg to 2000 kg
  • In pressure ranging from -0,95 … +1000 bar with accuracy from 0,025 %
  • In temperature ranging from -30 … +650 °C with accuracy from 0,08 Κ
  • In humidity from 15 … 95 % rH (at 25 or/and 40 οC) with accuracy ranging from 1,0 % rH
Certificates
Calibration
Certificates
Need to carry out a calibration

The calibration complies with the guidelines in force. The measurement results are documented in a calibration certificate and the calibrated meter is labeled with a calibration mark. Depending on your demands, you may opt for either a calibration by an accredited method or a calibration equivalent to the factory calibration.

Certificate sample

Click here to view the accredited services of our laboratory
